A custom pet bag programme is usually a size ladder rather than a single style, and the ladder is what determines how many colourways you can afford.

Why Stacking Is a Retail and Logistics Feature

Stackability is requested by brands for home storage and bought by retailers for shelf efficiency, and the two motivations lead to different designs. Understanding which one dominates is the first decision in the brief, because it determines whether the engineering goes into the base or into the silhouette.

For retail, stacking is about vertical shelf blocking. A stackable product lets a buyer present six units in the floor space that four would otherwise occupy, and it lets a brand build a visible tower of colourways at the end of an aisle. That is a planogram argument, and it is one of the few structural features a buyer will actively ask for.

For logistics, stacking is about pallet stability and cube. A unit that stacks squarely makes a stable pallet, survives a distribution centre, and arrives undamaged. A unit with a domed lid or a soft top makes an unstable pallet, and the damage rate shows up in the brand's own returns rather than in the retailer's.

For the customer at home, stacking is a weaker story than it sounds. Most households own one carrier, and two carriers stacked is a rare use case. The exception is a multi-pet household or a brand that has successfully sold a second unit, which is worth designing for but should not drive the geometry.

Our recommendation is to engineer for retail and logistics first and let home storage be a secondary benefit mentioned on the packaging. That ordering produces a product with a genuinely flat top and base, which is what makes all three use cases work.

There is a second retail benefit that gets less attention: a stack is harder to shoplift and easier to count. A three-unit stack is a single visual block for stock-taking and a single unit to secure, which matters in channels where shrinkage on pet accessories is meaningful. Buyers rarely raise it, but they notice it.

One caution: stackability conflicts with a soft, fashion-led silhouette. A slouchy tote cannot stack. Brands positioned on softness should not chase this feature, because the structure required will fight the entire brand language.

Stack Geometry: Flat Top, Matched Footprint and Interlock

Stacking works when three geometric conditions are met: the top surface is flat and load-bearing, the base footprint matches the top within a stated tolerance, and the vertical walls are close enough to plumb that the stack does not lean. All three are pattern and frame decisions, and all three are cheap to achieve at design stage and impossible to retrofit.

The top is the hardest condition on a soft product. A lid with a domed pad, a soft grab handle standing proud, or a decorative bow all break the load path. The working solutions are a flat framed lid with recessed hardware, a handle that folds into a recess, and a top plate inside the lid that spreads point loads.

The base footprint should match the top within roughly 5-10 mm. A base that is significantly smaller than the top creates a stack that narrows as it rises and becomes unstable by the fourth unit; a base that is larger creates an overhang that catches on shelf edges. State the tolerance on the tech pack and inspect it.

Interlock is the optional fourth condition, and there are three ways to achieve it. A recessed base that drops over a raised lip on the top below is the most positive and the most tooling-dependent. A pair of shallow moulded or stitched locators is lighter and cheaper. A high-friction base material is the simplest of all and adequate for two-to-three-unit stacks on a shelf.

The interlock choice should follow the intended stack height. Shelf displays of two or three units need friction and a flat top; warehouse pallets of eight or more need a positive mechanical interlock and a compression-tested structure.

Feet are the cheapest interlock aid available and the one most often forgotten. A set of four low-profile feet with a high-friction material raises the base slightly, protects the shell from wet floors, and gives the stack a defined seating plane that reduces sliding. Where a positive mechanical interlock is not justified by the volume, feet plus a flat top will carry a two or three unit shelf stack safely.

Finally, decide the maximum stack height and state it. Every material creeps under sustained load, and a stack that is safe for a week on a shelf may not be safe for a season in a warehouse. A stated maximum height is both an engineering statement and a liability statement.

Load Considerations: What the Bottom Unit Carries

The bottom unit in a stack carries every unit above it, and on a pet carrier that load path runs through the frame and the walls rather than through the base alone. Designing that path is the engineering core of a stackable program, and it is where most designs that look stackable actually fail.

The calculation is straightforward but frequently skipped. If a unit weighs 2 kg empty and the recommended stack is five high, the bottom unit carries 8 kg through its top surface and walls - before any product is inside. If the units are stored loaded, or if the stack is in a warehouse for months, the number rises and the duration matters as much as the magnitude.

Creep is the failure mode that catches brands out. A foam or a soft frame that holds 8 kg for an hour will slowly compress over a season, and the stack leans. Specify frame materials by their long-term compression behaviour rather than by their immediate strength, and avoid foam-only load paths in any product intended to be stacked for months.

Temperature and humidity belong in the same calculation. A warehouse in a hot climate softens foams and some adhesives, and a stack designed at room temperature can behave differently at 40 degrees. Where a program ships into hot markets, specify frame materials with a stated service temperature rather than a room-temperature figure.

Wall construction carries the load downward. A wall with a light internal frame, a stiffened lower third, or a corner post transmits load to the base; a wall with no support transmits it into the fabric and the bag bulges. Corner posts are the cheapest effective answer and they are invisible from outside.

Ventilation fields complicate the load path, because a mesh panel cannot carry compression. Keep mesh out of the top surface entirely and out of the upper third of the walls where compression concentrates - which is also where it contributes least to airflow on a stacked unit.

Ventilation and Access When Units Are Stacked

Stacking creates an animal-welfare question that a brand has to answer honestly: a stacked carrier has less open air around it than a carrier standing alone. The design response is to move the ventilation to faces that remain open in a stack, and to be clear about how long a stacked unit may be occupied.

The top face is fully covered in a stack, so any ventilation there is wasted while stacked. Side faces remain exposed, which argues for generous mesh on at least two sides rather than a single large panel on top. Our designers place the primary field on the two long side panels and treat any top ventilation as a secondary contribution.

Access should also remain functional in a stack. A front or end entry stays reachable when units are stacked; a top entry does not. Where a brand wants a stackable product, front or end entry is close to mandatory, because a customer cannot open a lid that has another bag sitting on it.

The honest commercial position is that a stacked unit is a storage or transit state, not an occupied state. State that on the packaging, and the brand both avoids a welfare complaint and gives the customer a clear rule to follow.

For retailers, this also simplifies the display conversation: stacked units are demonstration stock, and the selling unit is the one taken off the top. Plan the planogram so that at least one unit is displayed open and out of the stack, which also solves the access question at shelf.

Branding the Faces That Stay Visible in a Stack

Stacking changes which surfaces a customer sees, and the decoration plan has to be redrawn around that. In a two or three unit stack, the visible surfaces are the front face of every unit and the top of the highest one; the sides are partly occluded and the base is invisible.

The front face therefore becomes the primary brand surface, and it should carry the hero mark, positioned in the upper third where it stays visible even when the unit below is slightly proud. A mark placed centrally works on a single unit and disappears behind the shelf edge in a stack.

The top face of the highest unit is the second opportunity, and on a stackable product it is a flat, unbroken panel - the best print or embroidery surface in the whole design. A secondary mark, a repeated motif, or a size and colourway identifier belongs here.

Side panels should carry a reduced treatment: a woven flag, a contrast binding or a repeated micro-pattern. They are partly visible and they do the recognition work at distance, which is what matters when a customer walks down an aisle.

The table below sets out which surfaces carry which job, and how the stack changes the priority order.

One practical rule follows from this: keep hardware recessed on the top and proud nowhere on the base. A D-ring or a handle that stands proud on the top surface both breaks the load path and blocks the print area, and it is the most common reason a stackable sample fails its own design intent.

Shelf Blocking, Planograms and the Retailer Conversation

Stackability is one of the few structural features that gives a brand something concrete to say in a buyer meeting, and the conversation should be prepared with numbers rather than with adjectives. Three figures are worth bringing: units per linear shelf metre stacked versus unstacked, the recommended maximum stack height, and the footprint.

Units per shelf metre is the number a buyer cares about, because it converts directly into sales density. A stackable product that doubles from two to four units per shelf position is a measurable gain for the retailer, and it is the strongest argument available for granting the range more space.

Colourway blocking is the second benefit. A stack of three colourways reads as a brand statement from the end of an aisle in a way that three separate hanging bags do not, and it lets a brand present a coordinated palette without extra fixture cost.

Planogram support should be offered, not left to the retailer. A simple drawing showing the recommended stack, the open display unit beside it, and the colourway order is cheap for the brand to produce and disproportionately influential on how the range is presented.

Where a retailer asks for a taller stack than the structure supports, the answer is a fixture rather than a redesign. A simple acrylic shelf riser, or a branded two-tier stand, delivers the vertical presence a buyer wants without putting load on the product, and it costs less than the structural upgrade would. Keep the product stack at two or three and let the fixture do the blocking.

There is one risk worth naming: a stack is also a tipping hazard in a store. A tall narrow stack in a high-traffic aisle will be knocked over. Keep the recommended retail stack to two or three units and say so in the planogram, reserving taller stacks for the stockroom where nobody walks into them.

Cost, Materials and Structural Additions

Stackability costs money in structure, and the cost lands in the frame rather than in the fabric. Understanding where it goes lets a brand decide whether the feature is worth the premium for its particular price band.

The frame is the main line: corner posts, a top plate or stiffener, and a reinforced base. Depending on how positive the interlock needs to be, that is 1.00-3.00 dollars per unit and it is the bulk of the added cost.

Tooling appears only if the interlock is moulded. A recessed base and a raised lip produced as moulded parts carry a one-off tooling charge that has to be amortised across the first order, which is one reason MOQ 500 pieces per colourway is the practical floor. A stitched or webbing locator avoids tooling entirely at the cost of a less positive interlock.

Weight rises, and it matters on a pet carrier more than on most products. Structure to hold a stack typically adds 150-400 grams, which the customer feels when carrying the bag and which counts against any airline pet-weight limit.

Packaging interacts with stacking in one way that catches brands out. If the retail carton is designed to be stacked but the product inside is not, the two arguments contradict each other on the same shelf, and a buyer will notice. Keep the two consistent: either the product stacks and the carton stacks, or the product stands alone and the carton is sized for a shelf rather than a pallet.

The offsetting side is damage reduction. A stable stack travels better, arrives cleaner, and generates fewer transit claims, and in a channel with meaningful return rates that saving can exceed the structural cost within the first season.

Shelf-edge behaviour is worth one specific check, because it is where stacks fail in stores. Place a two-unit stack on a shelf with a 20 mm lip and push it gently: a stable stack resists, a marginal one slides. Reproducing that ten-second test in the sample room prevents the in-store breakage that no amount of compression testing will predict.

Material choice should favour compression performance over hand-feel at this point. A slightly stiffer shell and a denser frame foam are the right calls on a stackable product, even where the brand would otherwise prefer a softer drape.

Sampling, Compression Testing and Sign-Off

A stackable program needs a sampling activity that no other structure requires: a physical stack test with three or more units, loaded and left standing. Its job is to answer whether the stack stays plumb, whether the bottom unit deforms, and whether the interlock actually locates or merely looks as though it should.

Round one is a single unit, judged as a carrier: fit, entry, ventilation, silhouette. A stackable product that is poor as a carrier has no value in stacking, and this round should not be compressed.

Round two is the stack round. Build a three-unit stack on a level surface, load it to the recommended maximum with weighted units, and leave it for at least 48 hours. Then measure: stack height before and after, any lean, and any permanent deformation of the bottom unit. Most stackable designs pass a five-minute demonstration and reveal creep over two days.

Compression and transit performance of the packed stack should also be verified before bulk. Recognised methods published by ASTM International cover compression and vibration testing of packed cartons, and independent verification is available through SGS. The quality system behind the line is maintained to ISO 9001 requirements, so the same checks are repeatable across seasons.

Bulk release follows the range standard: pre-production check on first pieces, inline checks while the run is correctable, and final random inspection to the AQL 2.5 sampling plan with critical, major and minor classes. On a stackable unit the inspection plan should include a footprint tolerance check and a three-unit stack check on pulled samples, because a footprint drift of a few millimetres turns a stable stack into a leaning one.

One documentation note: state the maximum stack height, the footprint tolerance and the load rating on the tech pack and on the carton mark. Those three numbers are what make the feature defensible in a warehouse and in a retailer conversation.

Stackable and non-stackable in one range

Many brands end up with a stackable structured carrier and a soft non-stackable one, and the two should be made visually distinct rather than presented as variations of the same idea. Give the stackable product a squarer silhouette, a defined binding and a flat top, and let the soft product carry the relaxed language. A range in which some sizes stack and others do not creates a merchandising problem at shelf that no amount of packaging copy will solve.
